General Information
Degree of protection (IP): 65
Max. load of the LED light source: 300W
Max. load: 1200W
Colour: black
Nominal voltage: 230V~, 50Hz
Relay output: no
Presence detector: no
Adjustable daylight sensor (LUX): yes
Dimensions of the sensor – width (mm): 52mm
Installation: surface mounting
Dimensions of the sensor – height (mm): 80mm
Daylight sensor adjustment range (LUX): <3—2000lux
Dimensions of the sensor – depth (mm): 124mm
Adjustment of motion detection range (SENS): no
Adjustable time setting (TIME): yes
Lighting time adjustment range (TIME): min: 10 sek. ± 3 sek.; max: 7 min. ± 2 min.
Detection range: 12m
Detection angle: 360°/180°
Type of sensor: Infrared
