General Information
Supply voltage: 230V~, 50Hz
Max. load: 2000W
Max. load of the LED light source: 500W
Relay output: noA
Presence detector: no
Type of sensor: Infrared
Detection range: Ø20m
Dimensions of the sensor – width (mm): 172,5mm
Detection angle: 360°
Protection rating – IP: 65
Dimensions of the sensor – height (mm): 86,5mm
Dimensions of the sensor – depth (mm): 56mm
Adjustable daylight sensor (LUX): yes
Daylight sensor adjustment range (LUX): <3—2000lux
Installation: surface mounting
Adjustment of motion detection range (SENS): no
Adjustable time setting (TIME): yes
Lighting time adjustment range (TIME): min: 10 sek. ± 3 sek.; max: 30 min. ± 2 min.
Colour: white
Other features: Presence sensor
